Threaded Rod A2-70 M22x1000mm Stainless Steel DIN 976
Description
Threaded Rod A2-70 M22x1000mm Stainless Steel DIN 976
Threaded rod to DIN 976 standard with a diameter of M22 and a length of 1000 mm, manufactured from A2 (AISI 304) stainless steel in strength class A2-50. A versatile fastening element with a full metric thread along its entire length, providing maximum installation flexibility. The ideal solution for professional applications in construction, photovoltaic installations, and wherever corrosion resistance and reliable connections are required.
- Thread: M22 (metric ISO, pitch 3.5 mm)
- Length: 1000 mm
- Weight: 11.10 kg
- Material: Stainless steel A2 (1.4301)
- Strength class: A2-50 per DIN EN ISO 3506
- Tensile strength Rm: min. 500 N/mm²
- Yield strength Rp0.2: min. 210 N/mm²
- Corrosion resistance class: CRC II
- Standard: DIN 976 (replaces DIN 975)
DIN 976 threaded rods in A2 stainless steel are widely used in professional installations requiring durability and resistance to atmospheric conditions. They are an essential component for mounting photovoltaic structures, securing solar panels to roofs, and constructing PV arrays. They also perform excellently in construction – for fixing roof trusses, installing wall plates, suspending ceilings, and in ventilation and air conditioning systems.
Thanks to the full-length thread, the rod can be freely cut to the required dimension without any loss of functionality. Compatible with standard DIN 934 nuts, DIN 125 washers, and all types of chemical and mechanical fixings, including resin anchors and expansion sleeves.
A2 stainless steel (also referred to as V2A or AISI 304) is an austenitic chromium-nickel steel belonging to corrosion resistance class CRC II. It offers good corrosion resistance in atmospheric conditions and is suitable for use in equipment mounting, timber construction, balustrades, and architectural applications. It is not recommended for environments with high chloride content (swimming pools, coastal areas) – in such cases, A4 stainless steel should be selected.
Technical data
| Length [mm] | 1000 |
| Material | A2 - stainless steel |
| Thread type | M22 |
