Square aluminium tube 50×50×4 mm – closed profile L=2000 mm
Leave feedback on the product
Square aluminium tube EN AW-6060 T6/T66 (PA38, AlMgSi0,5). Closed section 50×50 mm, wall thickness 4 mm, length 2000 mm. Weight 3.98 kg. Raw, non-anodised surface.
Product code: 001-833
Product features
[PIM] Cat 144 #144
- Material Aluminium
- Wall Thickness [mm] 4
- Length [mm] 2000
- Height [mm] 50
Description
Square aluminium tube 50×50×4 mm – closed profile L=2000 mm
Square aluminium tube 50×50×4 mm is a robust closed profile with a square cross-section, ideal as a structural element in photovoltaic installations, balustrades, frames, and load-bearing structures. Thanks to the use of EN AW-6060 T6/T66 alloy (AlMgSi0,5 / PA38), the profile combines low weight with high rigidity and natural corrosion resistance — with no need for additional surface protection. The section length is 2000 mm, making planning easier and minimising material waste on site.
The raw, non-anodised surface allows for further processing — cutting, drilling, bending, and joining require no specialist tools. The profile is suitable wherever a lightweight yet rigid load-bearing structure is needed.
Technical Specification
- Cross-section: closed square tube
- External side (A): 50 mm
- Wall thickness (T): 4 mm
- Length: 2000 mm
- Dimensions (side × side × length): 50 × 50 × 2000 mm
- Weight: 3.98 kg (1.99 kg/m)
- Material: aluminium PA38 (EN AW-6060 T6/T66), alloy AlMgSi0,5
- Surface: raw (non-anodised)
Applications
- Aluminium structures and mounting frames
- Balustrades and handrails
- Load-bearing frames and structures for PV installations
- Furniture and decorative elements
- Modelling and DIY projects
The profile is available as part of a product range — in many cross-section size and wall thickness variants, allowing the optimum profile to be selected for the design loads.
