Solar DC cable 1x4mm² red MG Wires class D CPR
Availability:
In stock (large quantity)
Delivered within:
10 Business days
Weight:
0.06 kg
Description
DC Solar Cable 1x4mm2 Red MG Wires Class D – CPR
DC solar cable 1x4mm2 red MG Wires H1Z2Z2-K (class D – CPR) for photovoltaic systems.
MG Wires DC solar cable is a professional single-core cable designed specifically for use in photovoltaic installations. High-quality workmanship and compliance with the PN-EN 50618:2015-03 standard ensure durability, safety and reliability in all conditions.
Application:
- Connections between photovoltaic modules and module strings
- Connections of modules to inverter
- Roof-mounted, ground-mounted and indoor installations
- Possibility of direct burial (in accordance with UL 854)
Construction:
- Conductor: copper, tinned, stranded, class 5 according to PN-EN 60228 / VDE 0295
- Insulation: halogen-free cross-linked compound (white colour)
- Outer sheath: halogen-free cross-linked compound (black colour)
- Outer diameter: 6.6 mm
- Insulation thickness: 0.7 mm
- Sheath thickness: 0.8 mm
- Minimum insulation resistance at 20°C: 580 MΩ·km
Features:
- Rated voltage: 0.6/1kV AC
- Operating voltage: 1.5 kV DC (according to EN 50618)
- Insulation resistance: 1000 MΩ/km
- Maximum conductor temperature during cable operation: +90°C
- Maximum conductor temperature during cable operation (Long-term): +120°C/20000h
- Minimum ambient temperature for permanently installed cables: -40°C
- Minimum cable laying temperature: -25°C
- 50Hz Test voltage: 4000V
- Resistance to UV radiation, ozone, atmospheric conditions: In accordance with EN 50618
- Flame retardancy: In accordance with DIN EN 60332-1
- No aggressive fumes during combustion
- Min. bending radius for fixed installation: 4 x Ø
- Expected service life: 25 years
- Diameter: 35 cm x 22 cm H.
- Possibility of direct burial: Yes – in accordance with UL 854
Ładowanie tabeli porównawczej...
Ładowanie galerii...
Technical data
| Application | Solar DC |
| Cross-section [mm²] | 4 |
| Colour | Red |
| Conductor Material | Copper |
| CPR Class | D |
| Rodent Protection | No |
| Cable type | H1Z2Z2-K |
| Brand | MG WIRES |
