Snap hook with screw lock, galvanised 12×140 mm – safety nut, DIN 5299 D
Leave feedback on the product
Snap hook with screw lock 12×140 mm, C10 steel, galvanised. DIN 5299 D standard. Opening 20 mm, rated load 450 kg, breaking load 675 kg. Weight 0.2562 kg. Screw-on safety sleeve.
Product code: 002-425
Product features
[PIM] osprzet-do-lin-i-lancuchow #1023
- Fitting type Snap hook with screw lock
- Diameter 12
- Max. load capacity [kg] 450
Description
Snap hook with a spring-loaded gate and locking nut – once screwed shut, the gate cannot open accidentally; zinc-plated steel
About the product
The snap hook with screw lock to DIN 5299 D is used for connecting ropes, chains and fittings where the gate must not open by itself. It features a spring-loaded gate and a locking nut – once screwed shut, the gate cannot open accidentally.
The size 12 × 140 mm denotes the wire diameter d = 12 mm and the overall length L = 140 mm. The internal width of the eye D is 20 mm, and the gate opening C is 20 mm. Check that the component to be attached (eye, link or rope) fits through this opening. Select the carabiner to suit the load — do not exceed the working load limit of 450 kg. After attachment, screw the locking nut on the gate fully shut.
Material: C10 steel. Coating: zinc-coated. The zinc coating protects the steel against corrosion under typical conditions; where contact with salt, chemicals or constant moisture is expected, choose a version suited to the exposure conditions. The working load limit applies to loading along the carabiner's axis; sideways loading of the gate reduces the load-bearing capacity. The breaking load is 675 kg and is not the working load limit. The carabiner is not intended for lifting loads over people or for personal fall protection.
Selection and installation
- ✓Select the carabiner according to the load – do not exceed the working load limit of 450 kg.
- ✓Check that the component to be attached (eye, link or rope) fits through the gate opening C = 20 mm.
- ✓After attachment, screw the locking nut on the gate fully shut.
Important
The carabiner is not intended for lifting loads over people or for personal fall protection. The working load limit applies to loading along the carabiner's axis; sideways loading of the gate reduces the load-bearing capacity.
