Rectangular aluminium tube 60×100×3 mm – closed profile EN AW-6060 L=2000 mm
0
Description
Rectangular aluminium tube 60×100×3 mm – closed profile EN AW-6060 L=2000 mm
Rectangular aluminium tube 60×100×3 mm is a versatile closed profile with a length of 2000 mm, designed for constructing lightweight yet robust structures. Made from EN AW-6060 T64 alloy (AlMgSi0.5 / PA38), it combines low weight with high rigidity and natural corrosion resistance — without the need for additional surface protection.
The profile is easy to machine — cutting, drilling, milling and bending — allowing it to be efficiently adapted to individual installation requirements. The rectangular cross-section provides increased bending strength along the longer axis, making the profile ideally suited as a load-bearing element in frames, racks and balustrades.
Applications
- Aluminium structures and load-bearing frames
- Balustrades and handrails
- Equipment and installation frames
- Furniture structures and decorative elements
- Scale modelling and workshop projects
Dimensions and technical specifications
- Section: closed rectangular tube
- External width (A): 60 mm
- External height (B): 100 mm
- Wall thickness (T): 3 mm
- Length: 2000 mm
- Dimensions (W × H × L): 60 × 100 × 2000 mm
- Weight: 5.00 kg (2.50 kg/m)
- Material: aluminium EN AW-6060 T64 (PA38 / 3.3206), AlMgSi0.5 alloy
- Surface: raw (non-anodised)
The profile is available in a wide range of cross-sections and wall thicknesses — enabling selection of the optimum variant to meet the specific structural and installation requirements of your project.
Technical data
| Wall Thickness [mm] | 3 |
| Length [mm] | 2000 |
| Height [mm] | 100 |
| Material | Aluminium |
