Galvanised Wire rope grip for steel wire ropes 19–20 mm – DIN 741 equivalent
Leave feedback on the product
ZL Wire rope grip for 19/20 mm steel wire ropes, galvanised, compliant with DIN 741. M12 thread, width B 64 mm, dimension C 32 mm, weight 0.232 kg. U-bolt and nuts made of C15 steel, cast iron body. For forming loops and terminations in steel wire ropes.
Product code: 002-578
Description
Galvanised Wire rope grip for steel wire ropes 19–20 mm – DIN 741 equivalent
Wire rope grip of the ZL series for steel wire ropes with a diameter of 19/20 mm, manufactured in accordance with the DIN 741 standard. The product is designed for professional forming of loops and terminations in steel wire ropes in industrial and construction installations, as well as when assembling guying structures. The U-bolt and nuts are made of C15 steel, and the body of cast iron — this combination of materials provides high mechanical strength while maintaining the durability of the connection. The whole is covered with a galvanised coating, which protects the component against corrosion during outdoor use. The manufacturer recommends using a minimum of 6 grips per loop, with spacing between them in the range of 43.5–87 mm, which ensures a safe and durable rope attachment. Sale in units of 1 piece allows you to select the exact quantity for a specific project.
Key features of the ZL 19/20 wire rope grip
- Compliance with the DIN 741 standard — a proven standard in rope fittings
- U-bolt design with a cast iron body ensuring a secure clamping force on the rope
- Galvanised coating protecting against corrosion in outdoor conditions
- M12 thread allowing convenient installation and clamping adjustment with standard tools
- Precisely specified minimum number of grips and spacing — makes it easier to design terminations correctly
