Galvanised Rivet link 7 mm – chain connector, rated load 100 kg
Leave feedback on the product
Galvanised OZK Rivet link, low-carbon steel C5–C10. Rod diameter 7 mm, internal dimensions 14 x 36 mm, tolerance ±5%. Rated load 100 kg, breaking load 400 kg. Weight 0.046 kg. For joining lengths of chain.
Product code: 002-549
Product features
[PIM] osprzet-do-lin-i-lancuchow #1023
- Fitting type Rivet repair link
- Diameter 7
- Max. load capacity [kg] 100
Description
Galvanised Rivet link 7 mm – chain connector, rated load 100 kg
Galvanised OZK Rivet link 7 mm is a reliable piece of chain hardware designed for permanently joining lengths of chain. The link is made of low-carbon steel C5–C10 and finished with a zinc coating, which provides effective protection against corrosion in typical operating conditions. With a rod diameter of Ø 7.0 mm and internal dimensions of 14 × 36 mm, the link is compatible with chains of matching link thickness. Once riveted closed, the connection is permanent – the link should not be bent open for reuse, which ensures the safety and stability of the whole chain assembly.
Key features of the OZK 7 mm Rivet link
- Permanent chain connection achieved by riveting the ends of the link closed
- Galvanised coating protecting against corrosion in outdoor conditions
- Low-carbon steel C5–C10 providing suitable ductility during forming
- Compact internal dimensions of 14 × 36 mm, matched to chains with a 7 mm thickness
- Dimensional tolerance of ±5 % ensuring repeatable installation
The Rivet link is a simple but indispensable component in the everyday work of installers and service technicians. It is used wherever a quick chain repair is needed or two lengths must be joined into one working run. Joining involves inserting the ends of the link into the end links of the chain and then riveting them closed – the connection made this way is permanent and requires no additional specialist tools. The product is sold per piece, so you can order exactly as many links as a particular job requires.
