Forged Turnbuckle Eye-Eye 30x255 DIN 1480
Leave feedback on the product
Forged eye-eye turnbuckle M30 to DIN 1480, zinc-plated. Material: low-alloy structural steel. Overall length 254 mm, arm length 130 mm, diameter 31.5 mm. Minimum breaking force 185.83 kN, weight 4.05 kg.
Product code: 002-524
Product features
[PIM] osprzet-do-lin-i-lancuchow #1023
- Fitting type Turnbuckle
- Thread type M30
Description
Forged Turnbuckle Eye-Eye 30x255 DIN 1480
Eye-eye turnbuckle DIN 1480 in size M30 is a robust, forged tensioning element designed for professional tensioning of steel wire ropes, chains and guy lines. Made of low-alloy structural steel and protected with a zinc-plated coating, it offers high corrosion resistance even in demanding weather conditions. A minimum breaking force of 185.83 kN ensures safety in applications where heavy loads are involved, from installing mast guy lines and rope structures to tensioning safety lines on building sites. The eye ends on both sides (eye-eye) allow quick connection to shackles, wire rope thimbles and other rope fittings, which provides flexible configuration and efficient on-site installation.
Key benefits for the installer
- Forged construction providing high strength and durability compared with welded versions
- Eye ends on both sides (eye-eye) for universal connection to shackles, wire rope thimbles and pins
- Zinc-plated coating protects against corrosion in outdoor and industrial conditions
