ETI ETIMAT 6 – C 20A 3P 6kA miniature circuit breaker for PV and building installations
product unavailable
add to wish list
Description
ETI ETIMAT 6 – C 20A 3P 6kA miniature circuit breaker for PV and building installations
ETI ETIMAT 6 C 20A 3P is a three-pole miniature circuit breaker with a breaking capacity of 6 kA, designed to protect three-phase circuits against the effects of short circuits and overloads. The device, with a C trip characteristic, performs well both in AC photovoltaic installations and in conventional residential distribution boards, public buildings and industrial facilities. Mounting on a TH35 rail allows for quick and trouble-free replacement of the device in the distribution board without the need for additional adapters. The switching lever allows sealing in the "On" and "Off" positions, which is important during installation acceptance and protection against unauthorised tampering. The circuit breaker features a contact position indicator that facilitates visual monitoring of the operating status, and its construction provides protection against accidental contact with live parts. The ETIMAT 6 series can be fitted with auxiliary contacts and shunt trip releases, increasing the flexibility of protection system design.
Key features of the circuit breaker
- C characteristic — optimal for circuits with moderate inrush currents, typical of AC PV and general building installations
- Three-pole design ensuring simultaneous disconnection of all three phases upon detection of a short circuit or overload
- Ability to seal the lever in both positions — facilitates technical acceptance and meets network operator requirements
- Terminals with a capacity of 1–25 mm² allow connection of cables across a wide range of cross-sections
- Mounting on a standard TH35 rail — quick installation and replacement without specialist tools
Technical specification
| Electrical data | |
|---|---|
| Trip characteristic | C |
| Rated current | 20 A |
| Rated voltage | 400 V AC |
| Rated frequency | 50/60 Hz |
| Breaking capacity | 6 kA |
| Voltage type | AC |
| Construction | |
| Number of poles | 3P |
| Terminal capacity | 1–25 mm² |
| Mounting | TH35 rail |
| Manufacturer | |
| Manufacturer | ETI |
| Model / Series | ETIMAT 6 |
| Manufacturer catalogue number | 002145517 |
| Identification | |
| EAN | 3838895265726 |
| Weight | 0.2 kg |
Technical data
| Trip characteristic | C |
| Circuit breaker type | overcurrent |
| Rated current [A] | 20A |
| Number of poles | 3P |
| Breaking capacity [kA] | 6 kA |
| Brand | ETI |
