Unequal Aluminium Angle 80×40×2 mm – L-Profile, Length 2000 mm
0
Description
Unequal Aluminium Angle 80×40×2 mm – L-Profile, Length 2000 mm
Unequal aluminium angle 80×40×2 mm is a robust L-type profile made from EN AW-6060 T64 alloy (AlMgSi0.5 / PA38). The unequal legs (80 mm and 40 mm) allow flexible adaptation of the profile to support structures, mounting frames, trims and repair components. Thanks to its low self-weight of just 0.63 kg/m, the angle is easy to transport and process whilst retaining high rigidity and corrosion resistance.
The profile is supplied in a 2000 mm length with a raw (non-anodised) surface, giving complete freedom for further processing — powder coating, anodising, or leaving in its natural state. Aluminium alloy 6060 in T64 temper combines good machinability with sufficient strength for typical structural and installation applications.
Technical Specification
- Section type: unequal angle (L-profile)
- Leg A (longer): 80 mm
- Leg B (shorter): 40 mm
- Wall thickness T: 2 mm
- Length: 2000 mm
- Material: aluminium EN AW-6060 T64 (AlMgSi0.5 / PA38)
- Surface: raw (non-anodised)
- Weight per 2 m length: 1.26 kg
- Linear weight: 0.63 kg/m
Applications
The 80×40 mm aluminium angle is ideal wherever a lightweight yet rigid angular structural element is required. Typical applications include:
- Support structures and mounting frames
- Reinforcements and bracing of installation components
- Edge trims, covers and corner strips
- Repairs and ad-hoc workshop tasks
- Sub-structures in photovoltaic and construction systems
The unequal leg geometry allows optimal use of material — the wider leg (80 mm) provides a greater bearing or fixing surface, whilst the narrower leg (40 mm) minimises the space occupied on the other side of the angle. This geometry is particularly useful when mounting on narrow edges or in areas with limited space.
Technical data
| Height [mm] | 80 |
| Material | Aluminium |
| Wall Thickness [mm] | 2 |
| Length [mm] | 2000 |
