Rectangular aluminium tube 20×100×2 mm – closed profile L=2000 mm EN AW-6060
0
Description
Rectangular aluminium tube 20×100×2 mm – closed profile L=2000 mm EN AW-6060
Rectangular aluminium tube 20×100×2 mm is a robust closed profile with a rectangular cross-section, manufactured from aluminium alloy EN AW-6060 T64 (AlMgSi0.5 / PA38). Thanks to its excellent stiffness-to-weight ratio, it serves as a versatile structural component — equally suited to professional frames and load-bearing structures as to balustrades, handrails, and decorative elements. The section length is 2000 mm, enabling convenient design with minimal material waste.
The profile is supplied with a raw surface (non-anodised), giving complete freedom of finish — it can be anodised, powder-coated, or left in its as-manufactured state. Aluminium EN AW-6060 is characterised by natural corrosion resistance, ease of mechanical processing (cutting, drilling, bending), and good weldability, which significantly speeds up assembly work on site.
Technical Specification
Cross-section dimensions (A × B × T):
- External width (A): 100 mm
- External height (B): 20 mm
- Wall thickness (T): 2 mm
- Cross-section: closed rectangular tube
Dimensions and weight:
- Profile length: 2000 mm
- Overall dimensions (w × h × l): 20 × 100 × 2000 mm
- Total weight: 2.66 kg (unit weight 1.33 kg/m)
Material and surface:
- Material: aluminium EN AW-6060 T64 (AlMgSi0.5 / PA38 / 3.3206)
- Surface: raw (non-anodised)
Applications
The 20×100 mm rectangular profile is suitable wherever lightness, rigidity, and corrosion resistance are required. Typical areas of use include:
- Aluminium structures and load-bearing frames
- Balustrades, handrails, and fencing
- Furniture frames and interior fitting components
- Decorative and finishing elements
- Modelling, prototyping, and DIY projects
The profile is available in a range covering many cross-section sizes and wall thicknesses, making it possible to select the optimum variant for any specific project.
Technical data
| Material | Aluminium |
| Wall Thickness [mm] | 2 |
| Length [mm] | 2000 |
| Height [mm] | 100 |
