Overcurrent circuit breaker C 16A 1P 6kA MCN116E HAGER

Availability: In stock (large quantity)

Delivered within: 10 Business days

Delivery: The price does not include any possible payment costs check the delivery methods

Weight: 0.093 kg

Price / pcs.: £3.42 3.42

excl. shipping costs

Save more money with larger packaging!
The larger the packaging unit, the lower the unit price!

* Packaging options:

Piece
Package: 50 pieces
Package: 100 pieces
Package: 200 pieces

quantity pcs.

product unavailable

add to wish list

* - Field mandatory

Rating:

Vendor: HAGER

Product code: GPV-401-66

recommend to a friend

Description

Overcurrent circuit breaker C 16A 1P 6kA MCN116E HAGER

- MCN116E762

Overcurrent circuit breaker C 16A 1P 6kA MCN116E HAGER often referred to as a circuit breaker, performs the function of protecting cables and wires from the negative effects of overloads and short circuits. It is widely used in both residential and commercial construction.

This circuit breaker is designed for multiple tripping and offers greater sensitivity compared to traditional fuse links (fuses). Type C of this circuit breaker is characterized by delayed operation, which means that tripping occurs at 5-10 times the short-circuit current.

It is designed to protect installations supplying equipment with relatively low power, reaching up to a few kilowatts, thus ensuring safety and energy efficiency.

Specifications

Series and type

Overcurrent circuit breaker C 16A 1P 6kA MCN116E HAGER

Number of poles protected

Number of poles

1 P

Type of overcurrent circuit breaker

Rated short-circuit switching capacity Icn

6 kA

Rated switching voltage Ue

230 / 400 V

Rated frequency

50 / 60 Hz

Supply voltage type

Rated insulation voltage Ui

500 V

Rated withstand surge voltage Uimp

4000 V

Rated short circuit breaking capacity 230 V 50 Hz

6 kA

Rated operational short-circuit breaking current Ics

6 kA

Maximum power loss per pole according to the standard

3.5 W

Total power loss for rated current

2.32 W

Power loss per pole for rated current

2.32 W

Electrical strength (number of cycles)

4000 x

Mechanical strength (number of cycles)

20000 x

Tightening torque

2.8 Nm

Connection type

With screw

Input / output terminal capacitance for rigid wire (wire)

1/25 mm²

Input /output terminal capacity for flexible cable (wire)

1/16 mm²

Degree of protection

IP20

Dimensions

70 x 83 x 17.5 mm

Key features

Standard

EN 60898-1

RoHs directive

Compatible

Degree of pollution in accordance with IEC 60664 / IEC 60947-2

Available Configuration

Product code

Catalog no.

EAN

Model

GPV-401-66

MCN116E/HAG

3250614313660

MCN116E

Technical data

Trip characteristic	C
Circuit breaker type	overcurrent
Rated current [A]	16A
Number of poles	1P
Breaking capacity [kA]	6 kA
Brand	HAGER
