Surge arrester Type 1+2 (B+C) 4P 50kA 1.2kV SPD MOV TN-S/TT network contact SPA931 HAGER

Availability: In stock (large quantity)

Delivered within: 10 Business days

Delivery: The price does not include any possible payment costs check the delivery methods

Weight: 0.64 kg

Price / pcs.: £161.92 161.92

excl. shipping costs

* Packaging options:

Piece
Package: 50 pieces
Package: 100 pieces
Package: 200 pieces

quantity pcs.

Total:

product unavailable

add to wish list

* - Field mandatory

Rating:

Vendor: HAGER

Product code: GPV-401-101

recommend to a friend

Description

Surge arrester Type 1+2 (B+C) 4P 50kA 1.2kV SPD MOV TN-S/TT network contact SPA931 HAGER

- SPA931797

Surge arrester Type 1+2 (B+C) 4P 50kA 1.2kV SPD MOV TN-S/TT network contact SPA931 by HAGER also known as a lightning arrester, is designed to protect electrical installations from surges. This device is based on spark gaps and/or varistors, which consist of a base and an insert containing a protective element.

Its function is to limit the voltage pulse caused by a direct or near lightning strike on a power line. In order to ensure full protection, a three-stage surge protection system is used when supplying power to facilities, consisting of type 1, 2 and 3 surge arresters (otherwise known as B, C, D), which must be installed in cascade.

Specification

Manufacturer

HAGER

For the network

TN-S/TT

Protector class

B+C (Type 1+2)

Number of poles

Nominal discharge current (In)

50kA

Voltage level of protection

230 V

Maximum permissible operating voltage

335 V

Frequency of operation

50 / 60 Hz

IP degree of protection

IP20

Mounting method

Fixed installation to bus: TS 35

Series and type

SPD B+C T1+T2 MOV 4P surge arrester TN-S/TT network Iimp=50 kA In=50kA Up<1,2kV contact SPA931 HAGER

Number of modules

Optical signaling device

Yes

Rated switching voltage Ue (AC)

240 / 415 V

Maximum permanent operating voltage Uc

335 V

Voltage protection level Up

1.2 kV

Degree of protection Up L-PE / N-PE IEC 61643-11

1.2 kV

Degree of protection Up N-PE according to IEC61643-11

1.7 kV

Fuse

160 A

Dimensions

77.5 x 89.8 x 71.2 mm

Switching cross section of SSK input, with flexible conductor

0.4 / 1.5 mm²

Type of network

TT/TN-S

Mounting

TS rail

Approvals

KEMA

Tests according to EN 61643-11

T1 + T2

European Directive WEEE

Applies to

Available Configuration

Product code

Catalog no.

EAN

Model

GPV-401-101

SPA931/HAG

3250615515186

SPA931

Technical data

Application	AC (mains)
Surge Protector Type (SPD Class)	T1+T2 (B+C)
Rated Voltage [V]	275V AC
Number of poles	4P
Lightning Current (Iimp/In) [kA]	50 kA
Brand	HAGER
Protection Level (Up) [kV]	1,2 kV
