Steel gate stop with rubber bumper – bolt-on, 130x150/H65 mm

The stop is designed for swing gates — mounted to a flat surface using three bolts, it effectively blocks the gate leaf's movement at a defined point. The rubber layer minimises vibrations and noise on contact with the gate, while also acting as a soft protective barrier in the event of a vehicle wheel rolling over it.

The inner steel sheet is protected by a galvanised coating, ensuring high corrosion resistance even under prolonged exposure to variable weather conditions. As a result, the stop retains full functionality across many seasons without the need for maintenance.

Technical Specifications

• Material: steel + rubber coating
• Corrosion protection: galvanised
• Base dimensions: 150 × 130 mm
• Height: 65 mm
• Base thickness: 14 mm
• Colour: black
• Fixing: 3 mounting bolt holes (screw-fix)
• Weight: 0.76 kg

Key benefits for the installer:

• Quick installation — three mounting holes allow precise and secure bolting to the substrate
• Durable construction — steel core with galvanised sheet provides resistance to mechanical loads and corrosion
• Gate and vehicle protection — rubber coating absorbs impacts, protecting the gate leaf's paintwork and car tyres
• Quiet closing — flexible buffer minimises noise when the gate closes

Technical Drawing with Dimensions

The technical drawing shows the detailed dimensions of the stop and the layout of the mounting holes. The base measuring 150 × 130 mm features three holes of ø14 mm diameter for fixing bolts, two holes of ø25 mm and two holes of ø30.5 mm. The side through-hole has a diameter of ø27 mm. Mounting hole spacing: 83 × 92 mm (centre-to-centre), making it straightforward to mark out drilling points on the substrate.
