SCHNEIDER ELECTRIC

Schneider Electric PV Circuit Breaker 16A 2P 800V DC

Go to Product feedback

2-pole 16A overcurrent circuit breaker for photovoltaic installations, 800V DC voltage, B-curve characteristic. Breaking capacity 3kA at 650V DC, 1.5kA at 800V DC. DIN rail mounting, compliant with EN/IEC 60947-2 standard.

Go to full description

€86.36

Choose a variant:

Individual variants may differ in price

Packaging options

Piece

Package: 50 pieces

Package: 100 pieces

Package: 200 pieces

Quantity

pcs.

Availability:

In stock (large quantity)

Shipping time: 10 Business days

[PIM] wylaczniki-nadpradowe-i-silnikowe #90

Trip characteristic B
Circuit breaker type overcurrent
Rated current [A] 16A
Number of poles 2P

Description

Schneider Electric PV Circuit Breaker 16A 2P 800V DC

PV DC overcurrent circuit breaker B 16A 2P 800V C60PV-DC A9N61651 SCHNEIDER ELECTRIC

number of poles: 2

rated current [In]: 16 A

rated operating voltage [Ue]: 800 V DC

breaking capacity: 3 kA Icu at 650 V DC, 1.5 kA Icu at 800V DC

rated insulation voltage: 1000 V DC

rated impulse withstand voltage [Ui]: 6 kV

mounting: DIN rail

dimensions 132.7 x 72 x 77.4 mm

SPECIFICATION

Parameter	Value
Package weight	0.1 kg
Elektroklub	yes
Series	C60PV-DC
Characteristic	B
Rated voltage [V]	800 V DC
Rated current [A]	16A
Breaking capacity [kA]	6kA
Number of poles	2
Number of modules	1
Utilisation category	category A compliant with EN/IEC 60947-2
Suitability for isolation	yes, compliant with EN/IEC 60947-2
Control type	switch
