Residual current circuit creaker 3P+N 63A 30mA type AC CDC463J HAGER
Availability:
In stock (large quantity)
Delivered within:
10 Business days
Weight:
0.397 kg
Price / pcs.:
excl. shipping costs
Save more money with larger packaging!
The larger the packaging unit, the lower the unit price!
product unavailable
add to wish list
* - Field mandatory
Description
Residual current circuit creaker 3P+N 63A 30mA type AC CDC463J HAGER
Residual current circuit creaker 3P+N 63A 30mA type AC CDC463J HAGER is an advanced safety device that disconnects an electrical circuit if it detects a difference between the incoming and outgoing current.
It protects against electrical shock from direct and indirect contact and minimises the risk of damage to equipment, including the possibility of fire.
Key features
- Stable mounting on the mounting rail thanks to a robust metal bracket.
- Touch protection (IP2x) also with phase buses.
- The terminal cover prevents misplacement of the cable.
- The differential current indicator makes it possible to quickly identify whether the trigger was caused by a differential current or a manual switch-off.
- The actual contact position indicator for residual current and combination circuit breakers shows whether the contacts are actually mechanically open
- Safe working, even when live, thanks to the use of insulated screwdrivers, without damaging the housing
- Sealable, useful for special applications.
- Easy and safe installation and 100% compatibility with the previous series, allowing existing installations to be extended.
- All equipment meets the requirements set out in the Polish Standards and the conditions necessary for CE marking.
SPECIFICATION
Manufacturer
HAGER
With overcurrent device
No
Differential current
30mA
Rated current
63A
Number of poles
4P
Type
AC
Width expressed in number of modules
4
Rated insulation voltage Ui
500 V
Short-circuit resistance
6kA
Dimensions
70 x 83 x 70 mm
Operating temperature
-25 to 40 °C
Rated connection voltage Ue (AC)
230 / 400 V
Rated frequency
50 Hz
Rated withstand surge voltage Uimp
4 kV
Rated discharge current (IN 8/20µs)
0.25 kA
Rated switching capacity Im
1.5 kA
Total power loss for rated current
18.5 W
Power loss per pole for rated current
7.9 W
Short-circuit
No
Electrical endurance (number of cycles)
2000 x
Mechanical strength (number of cycles)
4000 x
Tightening torque
2.8 Nm
Cross-section of flexible wire (cable) in the clamp
16 mm²
Cross-section of rigid conductor (wire) in the terminal
25 mm²
Connection type
With screw
Standard
EN 61008-1
European RoHs Directive
Compatible
Degree of protection
IP20
Available Configuration
Technical data
| Circuit breaker type | residual current |
| Number of poles | 3P+N |
| Rated current [A] | 63A |
| Residual Current [mA] | 30 mA |
| Trip characteristic | AC |
| Brand | HAGER |
