Residual current circuit breaker with overcurrent protection B 16A 1P+N 6kA 30mA type AC ADC916D HAGER
Availability:
In stock (large quantity)
Delivered within:
10 Business days
Weight:
0.225 kg
Price / pcs.:
excl. shipping costs
product unavailable
add to wish list
* - Field mandatory
Description
Residual current circuit breaker with overcurrent protection B 16A 1P+N 6kA 30mA type AC ADC916D HAGER
Residual current circuit breaker with overcurrent protection B 16A 1P+N 6kA 30mA type AC ADC916D HAGER is a versatile protection device that combines the functions of a residual current and overcurrent circuit breaker.
SPECIFICATION
Manufacturer
HAGER
With overcurrent device
Yes
Rated current
16 A
Tripping characteristic curve
B
Rated short circuit switching capacity
6 kA
Tripping type of residual current device
AC
Rated residual current
30 mA
Number of poles
2 P
Number of modules
2
Rated operating voltage Ue (AC)
240 V
Rated insulation voltage Ui
2000 V
Rated withstand surge voltage Uimp
6000 V
Frequency
50 Hz
Total power loss for rated current
5.2 W
Electrical strength (number of cycles)
2000
Mechanical strength (number of cycles)
2000
Operating temperature
-25 to 40 °C
Storage temperature
-25 to 70 °C
Dimensions
83x35x68mm
Available Configuration
Technical data
| Circuit breaker type | RCD with overcurrent protection |
| Number of poles | 1P+N |
| Rated current [A] | 16A |
| Residual Current [mA] | 30 mA |
| Trip characteristic | AC |
| Breaking capacity [kA] | 6 kA |
| Brand | HAGER |
| Overcurrent Trip Characteristic | B |
