Residual current circuit breaker with overcurrent protection B 10A 1P+N 6kA 30mA type AC ADC910D HAGER
Availability:
In stock (large quantity)
Delivered within:
10 Business days
Weight:
0.223 kg
Price / pcs.:
excl. shipping costs
Save more money with larger packaging!
The larger the packaging unit, the lower the unit price!
product unavailable
add to wish list
* - Field mandatory
Description
Residual current circuit breaker with overcurrent protection B 10A 1P+N 6kA 30mA type AC ADC910D HAGER
Residual current circuit breaker with overcurrent protection B 10A 1P+N 6kA 30mA type AC ADC910D by HAGER is a versatile protection device that combines the functions of a residual current and overcurrent circuit breaker.
It protects the electrical installation from the effects of short circuits and overloads, protects electrical equipment in the home, prevents fires and is a key element of protection against electric shock, both from indirect and direct contact.
SPECIFICATION
Manufacturer
HAGER
Differential current
30mA
Rated current
10A
Number of poles
2
Tripping characteristic curve
B
Type
AC
Width expressed in number of modules
2
Rated insulation voltage Ui
2000 V
Short-circuit resistance
6kA
Dimensions
83x35x68mm
Operating temperature
-25 to 40 °C
Additional information
Integrated in the overcurrent module
Available Configuration
Technical data
| Circuit breaker type | RCD with overcurrent protection |
| Number of poles | 1P+N |
| Rated current [A] | 10A |
| Residual Current [mA] | 30 mA |
| Trip characteristic | AC |
| Breaking capacity [kA] | 6 kA |
| Brand | HAGER |
| Overcurrent Trip Characteristic | B |
