Residual Current Circuit Breaker 4P 40A 6kA 100mA Type A
Leave feedback on the product
4P 40A residual current circuit breaker | 100mA differential current | Type A. Breaking capacity 6kA, DIN rail mounting TH 35. Built-in contact position indicator, top or bottom supply connection.
Choose a variant:
Individual variants may differ in price
Packaging options
Product code:
Product features
[PIM] wylaczniki-roznicowopradowe #91
- Circuit breaker type residual current
- Number of poles 4P
- Rated current [A] 40A
- Residual Current [mA] 100 mA
- Trip characteristic A
- Breaking capacity [kA] 6 kA
Description
Residual Current Circuit Breaker 4P 40A 6kA 100mA Type A
Residual current circuit breaker 4P 40A 6kA 100mA type A PF6-40/4/01-A xPole Home 112934 EATON
- top or bottom supply of devices
- tripping is independent of mains voltage
- suitable for use with fluorescent lamps (with/without ballast)
- protection against earth leakage currents, residual currents
- built-in contact position indicator (green and red colours)
- double screw/busbar terminals (after busbar installation, screw terminal remains free)
- mounting on DIN rail TH 35
SPECIFICATION
| Parameter | Value |
|---|---|
| Package weight | 0.15 kg |
| Residual current | 100mA |
| Rated current | 40A |
| Number of poles | 4 |
| Type | A |
| Rated breaking capacity | 6kA |
| Rated current | 25, 40, 63 A |
| Rated tripping current | 30, 300, 100, 500 mA |
| Poles | 2, 4 |
| Sensitivity | A, AC, G, G/A, S, S/A |
| Possibility of supply from both sides | top/bottom |
| Colour | white |
| Dimensions | 45 x 80 x 70 mm |
| Degree of protection | IP40, IP54 (with moisture-resistant enclosure) |
| Mounting method | quick mounting with 2-position latch to DIN rail IEC/EN 60715 |
