PSG adjustable hinge for welding M12 galvanised with black ear
Description
PSG adjustable hinge for welding M12 galvanised with black ear
Adjustable M12 hinge for welding from PSG brand is a solid and proven mounting solution designed for swing gates and garden gates. The construction combines galvanised bolt with plate and black steel ear, ensuring corrosion resistance whilst maintaining high mechanical strength. Thanks to the possibility of precise adjustment after installation, the installer can quickly correct the gate leaf alignment without the need for dismantling — saving time and eliminating costly corrections.
A pair of hinges can withstand loads up to 65 kg on a leaf with a length of 2 m, making them an ideal choice for both light residential garden gates and medium-weight gates in industrial areas. Adjustment is carried out using a nut — simply tighten or loosen the hinge to compensate for construction sagging caused by intensive use or temperature changes.
Main advantages
- Post-installation adjustment — precise gate alignment adjustment without dismantling, ideal when leaf drops or thermal changes occur
- Corrosion resistance — bolt and plate galvanically galvanised, black steel ear — product designed for long-term outdoor operation
- High mechanical strength — construction resistant to wear and damage guarantees long-term reliability
- Welding installation — ear adapted for permanent welding to gate leaf or garden gate
- Load capacity up to 65 kg per pair of hinges with 2 m leaf length
Dimensions and technical parameters
- Manufacturer: PSG
- Material: steel
- Anti-corrosion protection: galvanised (black ear)
- Thread: M12
- Total height: 78 mm
- Ear width: 36 mm
- Bolt length: 36 mm
- Shaft diameter: 16 mm
- Thrust washer diameter: 52 mm
- Nut and washer assembly height: 18 mm
- Installation type: for welding
- Permissible load per pair of hinges (2 m leaf): 65 kg
- Weight per piece: 0.16 kg
- EAN: 5903313206488
Precise post-installation adjustment is a key feature of this hinge. In practice, the installer can correct the position of the gate leaf or garden gate at any time — simply tighten or loosen the adjustment nut. This is particularly useful when after some time of operation the construction drops slightly or when extreme temperatures affect the frame geometry. This eliminates the need for corrective welding and significantly reduces service time.
The hinge is designed for outdoor use and performs well both in private properties and in industrial areas. The galvanised surface of the bolt and plate effectively protects against rust, whilst the durable steel construction ensures resistance to dynamic loads accompanying daily gate opening and closing.
Technical data
| Thread type | M12 |
| Mounting Method | Weld-On |
| Material | Steel |
