MCB 6 kA, B-curve, 10 A, 3-pole
Leave feedback on the product
3-pole miniature circuit breaker with 10 A rated current and B characteristic. Breaking capacity 6 kA, operating voltage 240/415 V AC. Compliant with IEC/EN 60898-1, designed for photovoltaic systems.
Choose a variant:
Individual variants may differ in price
Packaging options
Product code:
Product features
[PIM] wylaczniki-nadpradowe-i-silnikowe #90
- Trip characteristic B
- Circuit breaker type overcurrent
- Rated current [A] 10A
- Number of poles 3P
- Breaking capacity [kA] 6 kA
Description
Miniature Circuit Breaker 6 kA, B-curve, 10 A, 3-pole
Miniature Circuit Breaker 6 kA, B-curve, 10 A, 3-pole Suitable for use in photovoltaic systems.
Ex9BN miniature circuit breakers are suitable for both domestic and industrial applications. They can be combined with a wide range of accessories, including auxiliary and signalling contacts, shunt releases, undervoltage and overvoltage releases, or additional RCD blocks. Various accessory combinations are possible. These combinations are limited only by the total number, not the type of accessories - all components are compatible with each other. Up to three auxiliary or alarm contact modules and up to two release modules can be used.
General Parameters
- Standards: IEC/EN 60898-1 and IEC/EN 60947-2 (partial)
- Rated short-circuit breaking capacity: 6 kA
- Number of poles: 3
- Tripping characteristic: B, C, D
- Rated current: 10 A
- Rated operating voltage: 240/415 V AC, 48 V DC per pole (3P)
- Accessories: Wide range of accessories
