High-voltage cable 35mm² (150kA) copper
Description
High-Voltage Cable 35 mm² Cu (150 kA) – Cross-Linked Polyethylene Insulation
High-voltage cable 35 mm² with a copper conductor is a certified solution for lightning current discharge in locations where the required isolation distance cannot be maintained. Thanks to its robust cross-linked polyethylene insulation, the cable safely carries impulse current even in direct proximity to electrical installations and metallic building components.
Verified performance – the cable holds the SEP-BBJ certificate confirming resistance to a 150 kA current impulse and a 200 kV voltage impulse. These parameters allow its use in Lightning Protection Class I, the most demanding category of lightning protection installations.
When to use it? A high-voltage cable is essential wherever the lightning current discharge route runs near electrical installations, metal pipes, ventilation ducts, or other conductive elements, and maintaining the standard isolation distance is not possible. The insulation reduces the required separation distance to just 750 mm, compared to the standard values applicable to uninsulated conductors.
Cable construction consists of a stranded copper conductor with a cross-section of 35 mm², a cross-linked polyethylene insulation layer, and an outer protective sheath. The total outer diameter is 18.5 mm, making it straightforward to route the cable through existing cable runs and to fit dedicated connection heads.
Technical specifications
- Conductor material: copper, cross-section 35 mm²
- Insulation: cross-linked polyethylene (XLPE)
- Outer diameter: 18.5 mm
- Impulse withstand: 150 kA (current), 200 kV (voltage)
- Isolation distance: 750 mm
- Lightning protection class: I
- Certificate: SEP-BBJ
Dedicated accessories: compatible connection heads are available for this cable – a mast connection head and an equipotential bonding connection head – ensuring a secure and durable connection within the lightning protection system.
Ładowanie tabeli porównawczej...
Ładowanie galerii...
Technical data
| Application | Lightning Protection |
| Cross-section [mm²] | 35 |
| Conductor Material | Copper |
| Rodent Protection | No |
