Hager Residual Current Circuit Breaker 40A 4P 30mA Type AC
Availability:
In stock (large quantity)
Delivered within:
10 Business days
Weight:
0.335 kg
Price / pcs.:
excl. shipping costs
Save more money with larger packaging!
The larger the packaging unit, the lower the unit price!
product unavailable
add to wish list
* - Field mandatory
Description
Hager Residual Current Device 40A 4P 30mA Type AC
Residual current device 4P 40A 30mA Type AC CDC440J by HAGER is an electrical device designed to immediately disconnect the circuit when it detects imbalances in the flow of outgoing and incoming currents.
Model CDC440J is primarily used to provide protection against electric shock in case of direct or indirect contact. Additionally, it helps to reduce the risk of equipment damage and prevents fires caused by electrical faults.
Key features
- Stable and secure mounting on DIN rail using a solid metal bracket.
- Provides touch protection (IP2x) even when using busbar systems.
- Terminal cover preventing incorrect wire connection, minimising the risk of installation errors.
- Residual current indicator enabling quick identification of whether tripping occurred due to residual current or manual disconnection.
- True contact position indicator showing whether the device contacts are actually mechanically open.
- Safe live working thanks to the possibility of using insulated screwdrivers, preventing housing damage.
- Sealing capability in special applications, ensuring control over unauthorised access.
- The device protects cables, property and human life from dangerous effects of electric current.
- All devices meet the requirements of British Standards and conditions necessary for CE marking, which testifies to their quality and safety.
- Possibility to expand existing installations thanks to 100% compatibility with the previous series, facilitating system modernisation.
Construction
| Parameter | Value |
|---|---|
| Number of poles | 4 P |
| Mounting | DIN rail |
Electrical characteristics
| Parameter | Value |
|---|---|
| Rated operational voltage Ue (AC) | 230/400 V |
| Rated frequency | 50 Hz |
Voltage
| Parameter | Value |
|---|---|
| Rated insulation voltage Ui | 500 V |
| Rated impulse withstand voltage Uimp | 4 kV |
Current
| Parameter | Value |
|---|---|
| Rated residual current dI | 30 mA |
| Rated discharge current (IN 8/20µs) | 0.25 kA |
| Rated making and breaking capacity Im | 1.5 kA |
| Rated conditional short-circuit current Inc according to BS EN 61008-1 | 6 kA |
| Rated current | 40A |
Power
| Parameter | Value |
|---|---|
| Total power losses at rated current | 6.5 W |
| Power losses per pole at rated current | 2.3 W |
Operation
| Parameter | Value |
|---|---|
| Time-delayed | no |
Endurance
| Parameter | Value |
|---|---|
| Electrical endurance (number of cycles) | 2000 |
| Mechanical endurance (number of cycles) | 4000 |
Dimensions
| Parameter | Value |
|---|---|
| Product depth | 70 mm |
| Product height | 83 mm |
| Product width | 70 mm |
Installation / Mounting
| Parameter | Value |
|---|---|
| Tightening torque | 2.8Nm |
Connection
| Parameter | Value |
|---|---|
| Flexible conductor cross-section (stranded) in terminal | 16 mm² |
| Solid conductor cross-section (wire) in terminal | 25 mm² |
| Type of connection | screw type |
Standard
| Parameter | Value |
|---|---|
| Standard | EN 61008-1 |
| European RoHS Directive | compliant |
Safety
| Parameter | Value |
|---|---|
| Degree of protection | IP20 |
| Type of residual current device | AC |
Operating conditions
| Parameter | Value |
|---|---|
| Pollution degree according to IEC 60664 / IEC 60947-2. | 2 |
| Storage temperature | -55 to 70 °C |
Ładowanie tabeli porównawczej...
Ładowanie galerii...
Files to download:
Technical data
| Circuit breaker type | residual current |
| Number of poles | 3P+N |
| Rated current [A] | 40A |
| Residual Current [mA] | 30 mA |
| Trip characteristic | AC |
| Breaking capacity [kA] | 6 kA |
| Brand | HAGER |
