Hager MCN116E – Miniature Circuit Breaker C 16A 1P 6kA
Leave feedback on the product
Hager MCN116E miniature circuit breaker, curve C, 16 A, 1P, 6 kA. Rated voltage 230/400 V AC, insulation voltage 500 V. DIN rail mounting, width 17.5 mm (1 module), screw terminals. Compliant with EN 60898-1 and the RoHS directive.
Choose a variant:
Individual variants may differ in price
Packaging options
Product code:
Product features
[PIM] wylaczniki-nadpradowe-i-silnikowe #90
- Trip characteristic C
- Circuit breaker type overcurrent
- Rated current [A] 16A
- Number of poles 1P
- Breaking capacity [kA] 6 kA
- Brand HAGER
Description
Hager MCN116E – Miniature Circuit Breaker C 16A 1P 6kA
Hager MCN116E is a single-pole miniature circuit breaker with C curve characteristics and a rated current of 16 A, designed to protect cables and conductors from the effects of overloads and short circuits. Thanks to its 6 kA breaking capacity, it meets the requirements of both residential and commercial installations. The type C characteristic means tripping occurs at 5–10 times the rated current, making it a suitable solution for circuits supplying equipment with moderate inrush currents — from lighting and sockets to small single-phase appliances. The circuit breaker is designed for repeated operation and offers greater sensitivity than traditional fuse links. DIN rail mounting, a compact width of 17.5 mm (1 module), and screw terminals allow for quick and reliable installation in distribution boards. The product complies with the EN 60898-1 standard and is in accordance with the RoHS directive.
Key benefits for the installer
- Curve C characteristic — delayed tripping eliminates unnecessary disconnections caused by brief inrush currents
- High breaking capacity ensures effective short-circuit protection in typical low-voltage installations
- Compact single-module design saves space in the distribution board
- Universal screw terminals accept a wide range of rigid and flexible conductor cross-sections — convenient installation without adapters
- High mechanical and electrical durability guarantees long, trouble-free operation
Technical specification
| Electrical data | |
|---|---|
| Rated current | 16 A |
| Tripping characteristic | C (5–10 × In) |
| Number of poles | 1P |
| Rated operational voltage Ue | 230 / 400 V AC |
| Rated frequency | 50 / 60 Hz |
| Rated insulation voltage Ui | 500 V |
| Rated impulse withstand voltage Uimp | 4000 V |
| Rated breaking capacity Icn | 6 kA |
| Rated service short-circuit breaking capacity Ics | 6 kA |
| Power losses | |
| Maximum power loss per pole | 3.5 W |
| Power loss per pole at In | 2.32 W |
| Durability | |
| Electrical durability | 4,000 cycles |
| Mechanical durability | 20,000 cycles |
| Connections and mounting | |
| Connection type | screw terminals |
| Rigid conductor cross-section | 1–25 mm² |
| Flexible conductor cross-section | 1–16 mm² |
| Tightening torque | 2.8 Nm |
| Dimensions (W × H × D) | 17.5 × 83 × 70 mm |
| Protection rating | IP20 |
| Standards and compliance | |
| Standard | EN 60898-1 |
| Pollution degree (IEC 60664) | 2 |
| RoHS directive | compliant |
| Weight | 0.093 kg |
| Manufacturer's catalogue number | MCN116E |
| EAN | 3250614313660 |
