Hager CDA225J – residual current circuit breaker 1P+N 25A 30mA type A
Leave feedback on the product
Hager CDA225J residual current circuit breaker, 1P+N, 25A, 30mA, type A. Insulation voltage 500V, short-circuit resistance 6kA. Width 2 modules, dimensions 83×35×70 mm, weight 0.199 kg. Operating range -25...+40°C.
Choose a variant:
Individual variants may differ in price
Packaging options
Product code:
Product features
[PIM] wylaczniki-roznicowopradowe #91
- Circuit breaker type residual current
- Number of poles 1P+N
- Rated current [A] 25A
- Residual Current [mA] 30 mA
- Trip characteristic A
- Brand HAGER
Description
Hager CDA225J – residual current circuit breaker 1P+N 25A 30mA type A
Hager CDA225J is a double-pole type A residual current circuit breaker with a rated current of 25 A and sensitivity of 30 mA, designed for shock protection in single-phase installations. The device detects both sinusoidal AC residual currents and pulsating DC currents, making it a suitable choice for circuits supplying photovoltaic inverters, electric vehicle charging stations and equipment with switch-mode power supplies.
The residual current indicator allows quick identification of whether tripping was caused by a leakage current or a manual switch-off — this shortens diagnostic time on site. The genuine contact position indicator shows whether the contacts are actually mechanically open, increasing safety during service work.
Practical features
- Type A — detects pulsating DC components, required for PV inverters and EV chargers
- Easy installation of cables and phase busbars — speeds up work in the switchboard
- Safe live working thanks to insulated screwdrivers — no risk of damaging the housing
- Sealing option available for special applications
- Compact design occupying only 2 modules on the DIN rail
Technical specification
| Parameter | Value |
|---|---|
| Manufacturer | Hager |
| Model | CDA225J |
| Number of poles | 1P+N (2) |
| Rated current | 25 A |
| Residual current (IΔn) | 30 mA |
| Trip type | A |
| With overcurrent protection | no |
| Rated insulation voltage (Ui) | 500 V |
| Short-circuit resistance | 6 kA |
| Width (number of modules) | 2 |
| Dimensions (H×W×D) | 83 × 35 × 70 mm |
| Weight | 0.199 kg |
| Operating temperature | −25 … +40 °C |
| EAN | 3250611619451 |
