Flanged mounting base for balustrade ⌀42.4 mm – steel with holes
Description
Flanged mounting base for balustrade ⌀42.4 mm – steel with holes
Flanged mounting base (collar) designed for mounting balustrade posts from tube with diameter 42.4 mm. Solid steel casting with three reinforcing ribs ensures rigid and durable connection of the post to the substrate. Three mounting holes enable secure fixing of the base to floor, ceiling or side of structure — ideal solution for installers of internal and external balustrades.
The element is ready for welding or press-fitting the balustrade tube into the central collar. Radially distributed reinforcing ribs increase the load capacity of the connection and prevent loosening of the post under lateral loading.
Dimensions and technical parameters
- External base diameter: 100 mm
- Internal collar diameter (tube fit): 42.4 mm
- Mounting hole pitch circle diameter (PCD): 74 mm
- Mounting hole diameter: 11 mm
- Overall height: 16 mm
- Number of mounting holes: 3
- Number of reinforcing ribs: 3
- Material: steel
Application
The flanged base finds application wherever stable mounting of vertical balustrade post to flat surface is required. Suitable for both internal balustrades (staircases, mezzanines, galleries) and external ones (terraces, balconies). Internal diameter 42.4 mm corresponds to standard balustrade tube ⌀42.4 mm (1¼"), which guarantees full compatibility with the most popular balustrade systems available on the market.
Technical data
| Finish | Raw |
| Material | Steel |
