ETI Residual current circuit breaker 4P 40A 100mA type A
Availability:
In stock (large quantity)
Delivered within:
10 Business days
Weight:
0.273 kg
Price / pcs.:
excl. shipping costs
Save more money with larger packaging!
The larger the packaging unit, the lower the unit price!
product unavailable
add to wish list
* - Field mandatory
Description
ETI Residual current circuit breaker 4P 40A 100mA type A
Residual current circuit breaker EFI-P4 A 40/0.1 from ETI is an advanced protective device to ensure safety against electric shock.
With a rated current of 40A and a sensitivity of 100mA, the Type A four-pole is ideal for protecting electrical installations in residential and commercial buildings. It is distinguished by its high quality workmanship, expandability with additional accessories and unique QR code for easy access to technical data.
Key features and functions:
- Shock protection: Protects against direct and indirect contact shock.
- High quality: Manufactured on a fully automated production line.
- Expandability: Possibility of fitting additional accessories (auxiliary contacts, triggers).
- Unique QR code: Quick access to technical data and test results.
- Flexible installation: Possibility to connect the power supply from both above and below.
Applications:
- Residential electrical installations
- Commercial and industrial buildings
- Protection of circuits with sensitive equipment
- Protection in areas with increased risk of shock
Benefits:
- Reliability: High quality workmanship guarantees long-lasting and effective protection.
- Versatility: Suitable for a wide variety of electrical installation applications.
- Ease of installation: The standard design allows quick installation on a TH35 rail.
- Safety: Effective protection against electric shock.
- Easy identification: QR code facilitates access to detailed product information.
- Durability: High resistance to environmental conditions and long service life.
SPECIFICATION
Manufacturer
ETI
With overcurrent device
No
Differential current
100mA
Rated current
40A
Number of poles
4
Type
A
Depth
68 mm
Degree of protection
IP20
Rated operational residual current IDn
0,01 A
Number of poles
3+N
Rated conditional short-circuit current Inc
10 kA
Trigger time
Without delay
Rated voltage
415 V
Rated frequency
50/60 Hz
Terminal capacity
1-25 mm2
Available Configuration
Technical data
| Circuit breaker type | residual current |
| Number of poles | 4P |
| Rated current [A] | 40A |
| Residual Current [mA] | 100 mA |
| Trip characteristic | A |
| Brand | ETI |
