ETI PV DC Surge Arrester Type 1+2 (Class B+C) 1100V 3P 65kA 3.8kV
Leave feedback on the product
Type 1+2 (Class B+C) surge protection device for photovoltaic installations, 1100V DC voltage, 3-pole. Impulse current 65kA (10/350), protection level 3.8kV. MOV technology with varistors with thermal protection. Optical fault indication (green/red indicator). Protection of PV modules against switching and atmospheric overvoltages.
Choose a variant:
Individual variants may differ in price
Packaging options
Product code:
Product features
[PIM] ograniczniki-przepiec #93
- Application DC (photovoltaic)
- Surge Protector Type (SPD Class) T1+T2 (B+C)
- Rated Voltage [V] 1100V DC
- Number of poles 3P
- Lightning Current (Iimp/In) [kA] 65 kA
- Brand ETI
- Protection Level (Up) [kV] 3,8 kV
Description
PV DC Surge Protective Device Type 1+2 (B+C) 1100V 3P 65kA 3.8kV ETITEC EM T12 PV 1100/6.25 Y 002440580 ETI
PV DC Surge Protective Device Type 1+2 (B+C) 1100V 3P 65kA 3.8kV ETITEC EM T12 PV 1100/6.25 Y 002440580 by ETI is specifically designed to protect photovoltaic installations, including PV modules, against both switching overvoltages and those resulting from indirect or direct lightning strikes.
It is particularly useful in buildings equipped with external lightning protection systems. The internal construction of the surge arrester includes two varistors, each protected by a thermal element - a disconnector, which enhances operational safety.
The surge arrester is also equipped with optical fault indication: a colour change of the indicator from green to red signals the need to replace the varistor cartridge, enabling quick and effective response in case of failure.
Specification
| Parameter | Value |
|---|---|
| Description | ETITEC EM T12 PV 1100/6.25 Y |
| Class name | Surge protective device |
| Type | T1, T2 |
| Continuous operating voltage Uc (V) | 1100 |
| Impulse discharge current Iimp (10/350) (kA) | 6.25 |
| Iimp - Impulse current (10/350) (kA) | 65 |
| In (8/20) | 20 |
| Imax (8/20) (kA) | 40 |
| Up - Voltage protection level (kV) | 3.8 |
| Leakage current | YES |
| Technology used | MOV |
| Internal fault signalling contacts (RC) | No |
| Number of modules | 3 |
| Installation depth (mm) | 86 |
