ETI Overcurrent Circuit Breaker B 16A 1P 6kA
Leave feedback on the product
B-curve miniature circuit breaker | 16A | Single-pole | 6kA breaking capacity. Rated voltage 230/400V AC, DIN rail TH35 mounting. Protection against short circuits and overloads, IP20 protection degree, lever seal option available.
Choose a variant:
Individual variants may differ in price
Packaging options
Product code:
Product features
[PIM] wylaczniki-nadpradowe-i-silnikowe #90
- Trip characteristic B
- Circuit breaker type overcurrent
- Rated current [A] 16A
- Number of poles 1P
- Breaking capacity [kA] 6 kA
- Brand ETI
Description
ETI Overcurrent Circuit Breaker B 16A 1P 6kA
Overcurrent circuit breaker B 16A 1P 6kA ETIMAT6 002111516 by ETI, also known as an MCB, plays a crucial role in protecting electrical installations.
Its primary function is to prevent damage resulting from short circuits and overloads, making it an essential component in every electrical system. By disconnecting the electrical supply, it ensures the safety of the entire installation.
ETIMAT overcurrent circuit breakers are particularly recommended for use in residential buildings, public utility facilities and in the industrial sector. These devices are equipped with a range of useful features, such as the option to mount additional auxiliary contacts, shunt releases and the ability to secure the lever in the "On" and "Off" positions through sealing. They also provide protection against accidental contact with live parts and are equipped with contact position indicators. Mounting on TH35 rail enables easy installation and replacement of circuit breakers.
SPECIFICATION
| Parameter | Value |
|---|---|
| Manufacturer | ETI |
| Tripping characteristic | B |
| Rated voltage [V] | 230/400 |
| Rated current [A] | 16 |
| Short-circuit current [kA] | 6 |
| Number of poles | 1 |
| Number of modules | 1 |
| Degree of protection (IP) | IP20 |
| Voltage type | AC |
| Rated voltage [V] | 230/400 |
| Rated frequency [Hz] | 50/60 |
| Terminal capacity [mm²] | 1/25 |
| Package weight [kg] | 0.15 |
