ETI Circuit Breaker B 16A 3P 6kA
Leave feedback on the product
3-pole miniature circuit breaker with 16A rated current and B characteristic. Breaking capacity 6kA, voltage 400V AC, frequency 50/60Hz. ETIMAT6 series with lever sealing option and auxiliary contact compatibility. Terminal capacity 1-25mm².
Choose a variant:
Individual variants may differ in price
Packaging options
Product code:
Product features
[PIM] wylaczniki-nadpradowe-i-silnikowe #90
- Trip characteristic B
- Circuit breaker type overcurrent
- Rated current [A] 16A
- Number of poles 3P
- Breaking capacity [kA] 6 kA
- Brand ETI
Description
ETI Overcurrent Circuit Breaker B 16A 3P 6kA
Overcurrent circuit breaker B 16A 3P 6kA ETIMAT6 002115516 by ETI, often referred to as an MCB, is a crucial device used to protect electrical installations against the effects of short circuits and overloads.
Its primary function is to automatically disconnect the power supply when an abnormality is detected, ensuring the safety of the entire electrical system. It is one of the most important components of any electrical installation, essential for maintaining its proper operation and protection.
ETIMAT overcurrent circuit breakers are designed for use in residential, public utility and industrial buildings. They offer the possibility of installing additional auxiliary contacts and shunt releases. The circuit breaker lever can be sealed in the "On" and "Off" positions, which increases operational safety. These devices effectively protect against accidental contact with live parts and are equipped with an indicator that shows the current position of the contacts.
Specification
| Parameter | Value |
|---|---|
| Manufacturer | ETI |
| Characteristic | B |
| Rated voltage | 400 V |
| Rated current | 16 A |
| Breaking capacity | 6 kA |
| Number of poles | 3 |
| Number of modules | 3 |
| Series and type | Overcurrent circuit breaker B16 A 3P 6kA ETIMAT6 002115516 ETI |
| Trip characteristic | B |
| Voltage type | AC |
| Rated frequency | 50/60 Hz |
| Terminal capacity | 1-25 mm2 |
