Dromet ring anchor expansion anchor for concrete PSRe M16x125 galvanised
0
Description
Dromet ring anchor expansion anchor for concrete PSRe M16x125 galvanised
The PSRe M16x125 ring anchor by Dromet is a reliable mechanical fastener designed for permanent fixing of structures in concrete and stone substrates. Thanks to its ring-shaped construction with expanding segments, it ensures high load capacity and secure anchoring — an ideal solution for installation teams working on photovoltaic systems, steel structures, balustrades or machine fixings.
The anchor holds European Technical Approval ETA 05/0242, a CE certificate and a national approval AT-15-7574/2008, confirming its full compliance with safety requirements and enabling its use in load-bearing construction connections.
Application
The anchor is designed for fixing metal profiles and structures, gratings, railings, machines and other structural elements and building fittings. It can be used in the following substrates:
- Non-cracked concrete of at least class B20 (C16/20)
- Natural stone with dense structure
- Solid brick
Technical parameters
- Thread: M16
- Overall length (L): 125 mm
- Shank diameter (fi): 16 mm
- Embedment depth (F): 110 mm
- Thickness of fixed element (E): 3 mm
- Installation hole depth (D): 168 mm
- Weight: 0.215 kg
- Sales unit: piece
Material and corrosion protection
- Material: structural steel
- Protection: electrolytic galvanising
- Construction: ring-shaped with nut and washer
Installation recommendations
Correct installation of the ring anchor requires observing a few key rules:
- The installation hole must be drilled perpendicular to the substrate surface
- After drilling, the hole must be thoroughly cleaned of dust and debris
- Insert the anchor into the hole using light hammer blows
- Use a torque wrench to tighten the nut
- After the fastener has expanded, the washer under the nut must be firmly pressed against the fixed element
- Detailed technical data and load tables are provided in approval AT-15-7574/2008 — the parameters contained therein must not be exceeded
Certificates and approvals
- European Technical Approval: ETA 05/0242
- Certificate: CE
- National technical approval: AT-15-7574/2008
