Dromet PSRe M14×145/37 galvanised ring expansion anchor for concrete
0
Description
Dromet PSRe M14×145/37 galvanised ring expansion anchor for concrete
The PSRe M14×145/37 ring anchor by Dromet is a steel mechanical fastener designed for permanent fixing of structures in non-cracked concrete. It performs well wherever fixing reliability matters — when installing mounting profiles, steel structures for photovoltaic systems, mesh walkways, railings, machinery and other facility equipment. Thanks to holding the European Technical Approval ETA 05/0242, CE certificate and national approval AT-15-7574/2008, the anchor meets the formal requirements necessary for professional construction projects.
The ring design ensures even expansion within the mounting hole, resulting in high load capacity and installation repeatability. The anchor is made of structural steel with corrosion protection in the form of electrolytic zinc coating, which protects the fastener against corrosion in indoor and outdoor conditions with moderate environmental aggressiveness.
Technical parameters
- Thread: M14
- Overall length (L): 145 mm
- Shank diameter: 14 mm
- Anchoring depth (F): 100 mm
- Thickness of fixed element (E): 37 mm
- Mounting hole depth (D): 150 mm
- Design type: ring
- Material: structural steel, electrolytic zinc
- Weight: 0.18 kg
- EAN: 5902706889970
Approved mounting substrates
- Non-cracked concrete, minimum class B20 (C16/20)
- Natural stone with a dense structure
- Solid brick
Installation recommendations
- Drill the mounting hole perpendicular to the substrate surface
- After drilling, clean the hole of dust and debris
- Insert the anchor into the hole using light hammer blows
- Use a torque wrench to tighten the nut
- After expansion, the washer under the nut must be firmly pressed against the fixed element
- Installation parameters comply with the AT-15-7574/2008 approval — they must not be exceeded
Certificates and approvals
- European Technical Approval ETA 05/0242
- CE certificate
- National technical approval AT-15-7574/2008
The Dromet PSRe M14×145/37 ring anchor is a proven, certified fastener for professional applications — both in photovoltaic structures and general construction. Sales unit: 1 piece.
