Adjustable welding hinge M12 – AISI 304 stainless steel, satin
Leave feedback on the product
Adjustable welding hinge M12 made of AISI 304 stainless steel, satin finish. M12 thread, total length 62 mm, threaded pin 47 mm, ear width 25 mm. Weight 0.13 kg. For left and right swing gates.
Product code: 001-218
Product features
[PIM] zawiasy #113
- Thread type M12
- Mounting Method Weld-On
- Material AISI 304
Description
Adjustable welding hinge M12 – AISI 304 stainless steel, satin
Adjustable (screw-type) welding hinge with M12 thread designed for mounting swing gates. Made from high-quality AISI 304 stainless steel with satin finish, ensures high corrosion resistance and years of trouble-free operation even in harsh atmospheric conditions. Thanks to its adjustable construction, it enables precise levelling of the gate leaf after installation completion — without the need to dismantle the hinge.
The universal design of the hinge allows application in both left and right gates. The M12 threaded pin enables quick and secure mounting — simply weld the hinge ear to the frame and screw the pin into the appropriate load-bearing element. Post-installation adjustment significantly speeds up installation work and eliminates problems with welding inaccuracies.
Advantages of adjustable hinge
- High corrosion resistance — AISI 304 stainless steel resistant to atmospheric factors
- Post-installation adjustment capability — precise gate leaf positioning without dismantling
- Simple and quick installation — M12 thread ensures secure connection
- Universal application — suitable for left and right gates
Technical parameters
- Material: AISI 304 stainless steel
- Finish: satin
- Thread: M12
- Total length: 62 mm
- Threaded pin length: 47 mm
- Ear width: 25 mm
- Pin diameter: 12 mm
- Weight: 0.13 kg
- Type: universal (left/right)
- EAN: 5901289674195
